Self Emission 3840x2160 Transparent LCD Screen OLED Backlight

China Shenzhen Topview Display Technology Co.,Ltd certification
China Shenzhen Topview Display Technology Co.,Ltd certification
Good product ,good service . Thank you guys so much,We will place more orders with you in 2018

—— Akhmad

Enthusiasm company, the product i got yesterday, the color i like it, the product i like.

—— Miguel

Very appreciated could cooperate with this professional team, very patience, professional company team!! Good product, i like it, my customer likes it.

—— Leo Zurita

I'm Online Chat Now

Self Emission 3840x2160 Transparent LCD Screen OLED Backlight

Self Emission 3840x2160 Transparent LCD Screen OLED Backlight
Self Emission 3840x2160 Transparent LCD Screen OLED Backlight
video play

Large Image :  Self Emission 3840x2160 Transparent LCD Screen OLED Backlight

Product Details:
Place of Origin: GuangDong,CN
Brand Name: Topview
Certification: CE,FCC,ROSH,C-TICK
Model Number: TD-O5501
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotiable
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 10-15days after payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 4000pcs per month
Detailed Product Description
Input Voltage: AC100~240V 50 /60 HZ Brightness: 0cd/m2
Contrast Ratio: 150000:1 Screen Position: Landscape Or Portrait
Technology: Optical Bonding Optional Function: Touch Screen
Operating System: Windows Android Linux Max Resolution: 3840*2160 Pixels
Name: 55inch OLED Backlight FREE Self Emission High Transparency Display With Outstanding Colors And Clearence Performance Glass Thickness: Tempered & Low-e Coatiing Glass 3mm/4mm
Cacacitive Touch: Available
Highlight:

Self Emission Transparent LCD Screen

,

3840x2160 Transparent LCD Screen

,

150nits OLED Backlight Lcd Panel



55inch OLED backlight FREE self emission high transparency display with outstanding



colors and clearence performance







Specification



1, Tranparent OLED LCD display
2, Flexible size and customization
3, Support Transparent video and picture display
4, Colorful


Transparent LCD Display: The inside exhibit can be seen while the pictures or vedios are displayed. It will strength cunstomer’s experience on product brand with the combination of dynamic information and the actual product display.






*** Customization/options

* Boot up logo/show customer’s logo on screen after turning on

* Touch panel

* WiFi/Ethernet, 4G

* Motion sensor



3. Time of making sample

* If have materials in stock: 3 working day

* If Customized sample: 10-15 working days



4. Price term

* Prepay 30% payment before production, the 70% balance being paid before shipment after inspection passed.



5. After sale service

* 12 months warranty if quality problems caused by the product itself & lifetime maintenance!

* RMA policy: The buyer and the seller each bear one-way freight



Active Screen size   54.46inches (1387.86mm) diagonal
Outline Dimension  1221.5(H)*699.35(V)mm (Typ)
Pixel Pitch  0.630mm*0.630mm
Pixel Format
1920 horiz. by 1080 vert. Pixels, RWBG Quad arrangement
Color Depth
10bit(R), 1.07Billon colors
Luminance ,White
400 / 150 cd/m2 (Center 1point ,Typ.)
Color Viewing Angle
R/L 120 (min.), U/D 120 (min.) (Δu’v’ ≤ 0.026)
Power  Consumption
Total 62.52W (Typ.) [Logic=11.52W, EVDD=51W @ IEC62087]
Weight
3.14kg (Typ.) (W/O C-PCB & Shield)
Display Mode
Normally Transparent
Transparent Ratio
38%(typ.)
Reflectivity
14% (typ.)
Surface Treatment
Hard coating(2H)



Self Emission 3840x2160 Transparent LCD Screen OLED Backlight 0

Self Emission 3840x2160 Transparent LCD Screen OLED Backlight 1

Self Emission 3840x2160 Transparent LCD Screen OLED Backlight 2

Self Emission 3840x2160 Transparent LCD Screen OLED Backlight 3



Self Emission 3840x2160 Transparent LCD Screen OLED Backlight 4















Self Emission 3840x2160 Transparent LCD Screen OLED Backlight 5







FAQ:
Q:How long is the warranty time for your products?
A: Our officially promised warranty time is one whole year after delivery at best.
Q: When will you make the delivery?
A: We can make the delivery within 3-15 working days or depend on the size and quantities of your order.
Q:what brand of screen are you using?
A:we are using Samsung,LG and AUO screen.
Q: Do you have your own enclosure factory?
A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
Q:Do you give any discount ?
A: We are Manufacturer, so we are able to give you the best price and best service at the same time.
Q:What payment methods your company accept?
A:We accept most of the payment methods,but mainly accept T/T, WesternUnion,Paypal and MoneyGram
