55'' 30'' Self Emission Capacitive Touch Display PCAP Table Stand Transparent OLED Signage

Large Image : 55'' 30'' Self Emission Capacitive Touch Display PCAP Table Stand Transparent OLED Signage

Product Details:

Place of Origin:	GuangDong,CN
Brand Name:	Topview
Certification:	CE,FCC,ROSH,C-TICK
Model Number:	TD-O5501

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	Negotiable
Packaging Details:	Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time:	10-15days after payment
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	4000pcs per month

Contact Now

Detailed Product Description

Input Voltage:	AC100~240V 50 /60 HZ	Color:	Transparent, 1.07Billon Colors
Contrast Ratio:	150000:1	Screen Position:	Landscape Or Portrait
Technology:	Optical Bonding	Optional Function:	Touch Screen
Operating System:	Windows Android Linux	Max Resolution:	38402160 /1366768(32")
Name:	55''30” Self Emission Capacitive Touch Display Glass PCAP OLED Transparent Table Stand Digital Signage Indoor Screen	Glass Thickness:	Tempered & Low-e Coatiing Glass 3mm/4mm
View Angle:	60/60/60/60(min.)	Machine Shell Material:	Aluminum + Tempered Glass + Metal
Highlight:	Self Emission Capacitive Touch Display , Table Stand Transparent OLED Signage , PCAP Transparent OLED Signage

55"30" Self Emission Capacitive Touch Display Glass PCAP OLED Transparent table stand digital signage

Technical characteristics:

Pixel Self-luminescence Technology

OLED (Organic Light Emitting Diode) belongs to the technology of pixel self-luminescence. Because each pixel can be turned on and off independently,

it can achieve amazing black display

effect. Through the details of each pixel to enhance the depth of the color, so that the picture is gorgeous and colorful.

OLED transparent screen can accurately express the transparency of the screen, and achieve the effect that ordinary screen can not achieve. It has self-luminous

pixels without backlighting. It can show extraordinary transparency effect and brilliance of color. When playing pictures and texts, you can also see the real scene behind the screen at the same time

Active Screen size	54.46inches (1387.86mm) diagonal
Outline Dimension	1221.5(H)*699.35(V)mm (Typ)
Pixel Pitch	0.630mm*0.630mm
Pixel Format	1920 horiz. by 1080 vert. Pixels, RWBG Quad arrangement
Color Depth	10bit(R), 1.07Billon colors
Luminance ,White	400 / 150 cd/m2 (Center 1point ,Typ.)
Color Viewing Angle	R/L 120 (min.), U/D 120 (min.) (Δu’v’ ≤ 0.026)
Power Consumption	Total 62.52W (Typ.) [Logic=11.52W, EVDD=51W @ IEC62087]
Weight	3.14kg (Typ.) (W/O C-PCB & Shield)
Display Mode	Normally Transparent
Transparent Ratio	38%(typ.)
Reflectivity	14% (typ.)
Surface Treatment	Hard coating(2H)

55'' 30'' Self Emission Capacitive Touch Display PCAP Table Stand Transparent OLED Signage 0

55'' 30'' Self Emission Capacitive Touch Display PCAP Table Stand Transparent OLED Signage 1

55'' 30'' Self Emission Capacitive Touch Display PCAP Table Stand Transparent OLED Signage 2

55'' 30'' Self Emission Capacitive Touch Display PCAP Table Stand Transparent OLED Signage 3

55'' 30'' Self Emission Capacitive Touch Display PCAP Table Stand Transparent OLED Signage 4

55'' 30'' Self Emission Capacitive Touch Display PCAP Table Stand Transparent OLED Signage 5

55'' 30'' Self Emission Capacitive Touch Display PCAP Table Stand Transparent OLED Signage 6

55'' 30'' Self Emission Capacitive Touch Display PCAP Table Stand Transparent OLED Signage 7

FAQ:
Q:How long is the warranty time for your products?
A: Our officially promised warranty time is one whole year after delivery at best.
Q: When will you make the delivery?
A: We can make the delivery within 3-15 working days or depend on the size and quantities of your order.
Q:what brand of screen are you using?
A:we are using Samsung,LG and AUO screen.
Q: Do you have your own enclosure factory?
A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
Q:Do you give any discount ?
A: We are Manufacturer, so we are able to give you the best price and best service at the same time.
Q:What payment methods your company accept?
A:We accept most of the payment methods,but mainly accept T/T, WesternUnion,Paypal and MoneyGram
