23.6-inch Self-service Terminal Payment Self Service Ticket Kiosk Self Service Kiosk with Printer

Large Image : 23.6-inch Self-service Terminal Payment Self Service Ticket Kiosk Self Service Kiosk with Printer

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	Topview
Certification:	CE, C-TICK, FCC, RoHS
Model Number:	TD-S236

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	negotiable
Packaging Details:	Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time:	10-15 days after payment
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	3000pcs per month

Contact Now

Detailed Product Description

Material:	Aluminum Edging+Toughened Glass	Screen Size:	21.5/23.6/32inch
CPU:	Android RK3288	Name:	21.5 Inch Flexble Customized Touch Scan Code Print Receipt Function Self-service Ordering POS Machine With Android System
Measure Distance:	1meter	OS:	Android 11
Touch Screen:	Capacitive Touch Screen	Application:	Shopping Mall, Bank, Hotel, Restaurant Etc..
Highlight:	Self Service Ticket Kiosk with Printer , 23.6-inch Self Service Ticket Kiosk , Self Service Ticket Kiosk

23.6-inch Self-service Terminal Payment Self Service Ticket Kiosk Self Service Kiosk with Printer

User Manual Of Indoor Touch Kiosk.pdf

 Main Features◆High end design, perfect for self-ordering and queuing application;
◆Fashionable design with LED lighting strip at the bottom;
◆Full HD brand new original panel;
◆Built in sensitive 10 points capacitive touch;
◆Built in 80mm thermal printer, 58mm thermal printer(optional);
◆Built in sensitive QR scanner(optional);
◆Built in 2M/5M/8M pixels camera(optional);
◆NFC modules can be customized;
◆Windows 7, 8.1 and 10 trial version or Android OS (optional);
◆Support Ethernet, WIFI network, and can customize 3/4G function;
◆Industrial level design, support 24/7 working;
◆CE, RoHS, TELEC and PSE certified
◆ISO9001 and ISO14000 certified;


			Panel size
			21.5"TFT-LCD

			Display area(mm)/mode
			476.64(W)×268.11(H) mm

			Maximum resolution
			1920*1080

			Display color
			16.7M

			Pixel Pitch(mm)
			0.63(H)×0.63(V)

			Brightness (nits)
			350cd/m2

			Contrast
			3000:1

			Visual angle
			178°/178°

			Response time
			5ms

			Input and output

			RJ45
			Included(Network version only)

			WIFI Module
			Included(Network version only)

			USB
			2

			SD
			1 (Compatible MMC/MS)

			L/R audio input
			1 (RCA*2)

			L/R audio output
			1 (RCA*2)

			Speaker
			2×5W(9Ω)

			Video

			Color system
			PAL/NTSC/SECAM

			Remote controller
			IR Remote Controller

			OSD display( screen menu display)

			Menu language
			Chinese/English

			Power

			Power supply
			AC100~240V 50/60 HZ

			Maximum power consumption
			≤230W

			Standby power consumption
			<5W

			Temperature

			Working temperature
			0°C~50°C

			Storage temperature
			-20°C~60°C

			Working humidity
			85%

			Storage humidity
			85%

			Appearance

			Panel color/appearance
			White,black,Silver, Customized

			Panel material
			Metal case SPCC

			Installation
			Wall mount,Floor stand

			Detailed functions

			Video format
			MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI

			Audio format
			Wave/MP3/WMA/AAC

			Image format
			JPEG/BMP/TIFF/PNG/GIF

			Image resolution
			480P/720P/1080P

			Andriod specifications

			Andriod system
			Android 7.1 support multi-language with wifi moulde

			CPU
			1.8 Ghz/quad-core RK3288

			RAM
			2G DDR3

			ROM
			16G

			Hand sanitizer

			Induction spray
			Yes

			The trial of liquid
			Alcohol/disinfectant

			The product capacity
			hand sanitiser 1000ML

			ultraviolet sterilization
			Yes

FAQ:

Q: How long is the warranty time for your products?

A: Our officially promised warranty time is one whole year after delivery at best.
Q: When will you make the delivery?

A: We can make the delivery within 3-15 working days or depend on the size and quantities of your order.
Q: what brand of screen are you using?

A:we are using Samsung,LG and AUO screen.
Q: Do you have your own enclosure factory?

A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
Q: Do you give any discount ?

A: We are Manufacturer, so we are able to give you the best price and best service at the same time.
Q: What payment methods your company accept?

A:We accept most of the payment methods,but mainly accept T/T, WesternUnion,Paypal and MoneyGram
