Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks

Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks
Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks
video play

Large Image :  Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks

Product Details:
Place of Origin: Guangdong, China
Brand Name: Topview
Certification: CE, C-TICK, FCC, RoHS
Model Number: TD-S236
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: negotiable
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 10-15 days after payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 3000pcs per month
Contact Now
Detailed Product Description
Material: Aluminum Edging+Toughened Glass Screen Size: 21.5/23.6/32inch
CPU: Android RK3288 Name: Floor Stand Self Service Ordering And Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks
Measure Distance: 1meter OS: Android 11
Touch Screen: Capacitive Touch Screen Application: Shopping Mall, Bank, Hotel, Restaurant Etc..

Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks

User Manual Of Indoor Touch Kiosk.pdf




Main Features

◆High end design, perfect for self-ordering and queuing application;

◆Fashionable design with LED lighting strip at the bottom;

◆Full HD brand new original panel;

◆Built in sensitive 10 points capacitive touch;

◆Built in 80mm thermal printer, 58mm thermal printer(optional);

◆Built in sensitive QR scanner(optional);

◆Built in 2M/5M/8M pixels camera(optional);

◆NFC modules can be customized;

◆Windows 7, 8.1 and 10 trial version or Android OS (optional);

◆Support Ethernet, WIFI network, and can customize 3/4G function;

◆Industrial level design, support 24/7 working;

◆CE, RoHS, TELEC and PSE certified

◆ISO9001 and ISO14000 certified;





Panel size 21.5"TFT-LCD/24" 27" 32”
Display area(mm)/mode 476.64(W)×268.11(H) mm/531.36(W)*298.89(H)mm
Maximum resolution 1920*1080
Display color 16.7M
Pixel Pitch(mm) 0.63(H)×0.63(V)
Brightness (nits) 350cd/m2
Contrast 3000:1
Visual angle  178°/178°
Response time 5ms
Input and output
RJ45 Included(Network version only)
WIFI Module Included(Network version only)
USB 2
SD 1 (Compatible MMC/MS)
L/R audio input 1 (RCA*2)
L/R audio output 1 (RCA*2)
Speaker 2×5W(9Ω)
Video
Color system PAL/NTSC/SECAM
Remote controller IR Remote Controller
OSD display( screen menu display)
Menu language Chinese/English
Power
Power supply AC100~240V 50/60 HZ
Maximum power consumption ≤230W
Standby power consumption <5W
Temperature
Working temperature 0°C~50°C
Storage temperature -20°C~60°C
Working humidity 85%
Storage humidity 85%
Appearance
Panel color/appearance White,black,Silver, Customized
Panel material Metal case SPCC
Installation Wall mount,Floor stand
Detailed functions
Video format MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI
Audio format Wave/MP3/WMA/AAC
Image format JPEG/BMP/TIFF/PNG/GIF
Image resolution 480P/720P/1080P
Andriod specifications
Andriod system  Android 11 support multi-language with wifi moulde
CPU 1.8 Ghz/quad-core RK3288
RAM 2G DDR3
ROM

16G
Optional Function
Optional Function  Built-in RFID / NFC Reader / POS
Built-in HD Camera
Built-in thermal printer 80mm
Built-in QR code scanner
Upgrade to i3, i5 or i7 Processor





Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks 0

Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks 1





Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks 2

Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks 3



Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks 4



Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks 5

Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks 6



Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks 7







Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks 8

Floor Stand Self Service Ordering and Payment Kiosk Support Customization 24 27 32 Inch Self Ordering Payment Kiosks 9



FAQ:
Q: How long is the warranty time for your products?
A: Our officially promised warranty time is one whole year after delivery at best.

Q: When will you make the delivery?
A: We can make the delivery within 3-15 working days or depend on the size and quantities of your order.

Q: what brand of screen are you using?
A:we are using Samsung,LG and AUO screen.

Q: Do you have your own enclosure factory?
A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.

Q: Do you give any discount ?
A: We are Manufacturer, so we are able to give you the best price and best service at the same time.

Q: What payment methods your company accept?
A:We accept most of the payment methods,but mainly accept T/T, WesternUnion,Paypal and MoneyGram
